ASTM D149 Test Machine 100KV Electrical Strength Testing Equipment As Per IEC 60243-1 Lab Testing Apparatus

Gambar besar : ASTM D149 Test Machine 100KV Electrical Strength Testing Equipment As Per IEC 60243-1 Lab Testing Apparatus

Detail produk:

Tempat asal:	CINA
Nama merek:	DAXIAN
Sertifikasi:	IEC60243-1, IEC60243-2, ASTM D149
Nomor model:	DX8388A

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 set
Harga:	Dapat dinegosiasikan
Kemasan rincian:	Kasing kayu
Waktu pengiriman:	30 hari setelah pesanan dikonfirmasi
Syarat-syarat pembayaran:	L/C, D/A, D/P, T/T, Western Union, MoneyGram, Tunai
Menyediakan kemampuan:	30 set per bulan

Kontak

ASTM D149 Test Machine 100KV Electrical Strength Testing Equipment As Per IEC 60243-1 Lab Testing Apparatus

Deskripsi

Tegangan kerusakan:	0 ~ 100kv	Berlaku:	Bahan isolasi
Standar:	IEC 60243-1	Kecepatan booting:	100, 200, 500, 1000, 2000, 5000 （kV/s）
Ketepatan:	≤ 2 ％	Berat:	200kg
Dimensi:	L1400* W1040* H1500 mm	Kapasitas transformator:	10 kVA
Menyoroti:	ASTM D149 test machine 100KV , electrical strength testing equipment IEC 60243-1 , lab testing apparatus for rubber

100KV IEC 60243-1 Power Frequencies Electrical Strength Testing Equipment

Application:

This tester is suitable for measuring the breakdown strength and withstand voltage time of solid insulating materials such as plastic, film, resin, mica, ceramics, silica gel, glass, insulating paint, etc. in air or liquid medium, it can measure the breakdown strength and withstand voltage time under power frequency (48 ~ 62Hz) or corresponding DC voltage.

Standards:

IEC60243-1

IEC60243-2

Specifications:

Breakdown voltage	0~50kV
Booting speed	100,200,500,1000,2000,5000(KV/S)
Voltage measurement accuracy	≤ 2％
The leakage current selection	1~100 mA
Methods of test	DC & AC
Supply power	AC220V 50/60Hz
Dimension	L 1400* W 1040* H 1500 mm
Weight	200kg

1. Booting speed control: Electrical automatic control

2. Methods of booting: Automatic program-controlled

3. Power Frequency: sine wave 50Hz/60HZ

4. Transformer capacity: 10 KVA

5. AC 0~50 KV (continuously adjustable)
